Tascam DR-40 V.2 4-Track Handheld Digital Audio Recorder (Black)

Tascam DR-40 specs






Type
Hand-held 4-track digital audio recorder


Recording/Reading Methods
SD or SDHC card (64 MB to 32 GB)


Recording Bit Rate
WAV: 16 and 24-bit MP3: 32-320 kbps, VBR


Sampling Frequency
WAV: 44.1, 48, or 96 kHz MP3: 44.1 and 48 kHz


Number of Channels
4 (2 Stereo)


Recording Time
All times are for a 1GB memory card Stereo Mode: MP3: 17 hours 21 mins (128 kbps), 6 hours 56 mins (320 kbps) WAV: 1 hour 34 mins (16-bit/44.1 kHz), 1 hour 26 mins (16-bit/48 kHz), 28 mins (24-bit/96 kHz)


Frequency Response
20 Hz~20 kHz +1/-3dB (44.1 kHz, EXT IN-LINE OUT, JEITA) 20 Hz~22 kHz +1/-3dB (48 kHz, EXT IN-LINE OUT, JEITA) 20 Hz~40 kHz +1/-3dB (96 kHz, EXT IN-LINE OUT)


Total Harmonic Distortion (THD)
< 0.05% (44.1/48/96 kHz, EXT IN-LINE OUT)


S/N Ratio
> 92 dB (44.1/48/96 kHz, EXT IN-LINE OUT)


A/D Conversion
24-bit


D/A Conversion
24-bit


Speed Adjustment
50-150% without affecting pitch


Connectors
2 x XLR/TRS combo inputs 1 x 3.5mm headphone/line out 1 x high-speed mini-B USB 2.0 port 1 x remote jack


Input Impedance
Mic: 2.2 kOhms Line: 10 kOhms


Input Level
Nominal: -19 dBV mic, +4 dBu line Max: -3 dBV mic, +20 dBu line


Output Impedance
12 Ohms


Output Level
Nominal: -14 dBV (10 kOhms) Max: +2 dBV (10 kOhms)


Microphone
Adjustable Stereo Condenser (X/Y and A/B)


Headphone Output
20 mW + 20 mW (32 Ohms)


Speaker
0.3 W, Mono


Filter
40/80/120 Hz Low Cut


Battery Type/Life
3 x AA (Alkaline or NiMH) Up to 15 Hours of Continuous Operation, Phantom Power Off


Power
100-240 VAC, 50/60 Hz (via Optional AC Adapter)


Power Consumption
2.5 W Max


Dimensions (WxHxD)
Mics Open: 3.54 x 6.1 x 1.38" / 90 x 155 x 35 mm Mics Closed: 2.76 x 6.1 x 1.38" / 70 x 155 x 35 mm


Weight
7.5 oz / 213 g (Without Batteries)


System Requirements
Windows XP, Vista, or 7, Pentium 300MHz, 128MB RAM, USB 2.0 Recommended macOS v10.2 or Later, Power PC G3, G4, or G5 266MHz Min, 64MB RAM, USB 2.0 Recommended






Packaging Info


Package Weight
1.15 lb


Box Dimensions (LxWxH)
8.0 x 5.5 x 3.2"
