TRITON AUDIO D2O MONO MICROPHONE PREAMP

PRODUCT DESCRIPTION
The Triton Audio D2O Mono Preamp is a low noise discrete microphone preamp - a development of the famous German V series preamps, widely recognized as one of the best sounding preamps. These preamps were used at Abbey Road to record The Beatles, Pink Floyd among many others. Today V series preamps are still in demand, although most units are now at least 35 years old and need to be rebuilt or refurbished.
The D2O mono is a single unit preamp housed in a rugged aluminum enclosure. The portable format is ideal for the new generation of mobile recording interfaces.
D2O's general layout consists of a Lundahl 1571 input transformer followed by 2 single ended gain stages. The second gain stage can be selected to be either a high gain FET or a Tube stage. when the high gain, all FET circuit is engaged D2O becomes an ideal companion for microphones with a relatively low output like ribbon microphones. With the hybrid FET/Tube circuit is engaged the sonic benefits of having a tube in the signal path can be utilized. Output drive is supplied by a discrete low impedance FET buffer with superb sonic properties. Quality Paper in oil coupling capacitors are used, all other used components are high-end grade as well.
LOW NOISE/LOW ESR POWER SUPPLY
In single ended preamp designs the quality of the power supply is crucial, D2O is fitted with a discrete low ESR voltage regulator built with low noise components enabling optimal performance to the amplifier circuit.
SWITCHABLE TRANSFORMER RATIO/INPUT IMPEDANCE
By selecting the transformer ratio switch a selection between a 1:1.75 (LO) or 1:3.5 (HI) transformation ratio can be made. Besides setting voltage gain, this also switches the input impedance of the amplifier between 2.25 kOhm and 6.25 kOhm. Different transformation rate and impedance selection options are very desirable as they allow for more sonic options from the connected microphone.
SELECTABLE ALL FET OR TUBE-FET CIRCUIT
The Tube-FET switch determines whether D2O functions with the hi-gain, all FET or hybrid Tube-FET circuit, each with its unique sonic character.
FEATURES

Stepped attenuator
Phase reverse switch
Phantom power
Overload indicator
Separate low noise power supply
Comes with 1x Triton Audio Airhead for attenuation
70/60 dB of clean amplification
Based on the German V series preamps
All JFET or Tube/FET mode
Heavy duty enclosure
Mobile and flexible format









PRODUCT SPECIFICATIONS



CONDITION
New


TUBE OR SOLID STATE
Tube/Solid State Hybrid


CHANNELS
Single-Channel


CHASSIS
Desktop


INPUT CONNECTORS
Analog XLR


OUTPUT CONNECTORS
1/4-inch TRS, Analog XLR



www.music-blvd.com $765/699USD
