Vox Copperhead Drive - Valve Distortion Pedal Copper

Genuine overdrive and distortion tones with the feel of a real tube amp.

Inspired by thick and punchy British amp tones, the Mystic Edge goes beyond the amp-in-a-box category to offer a truly flexible valve distortion pedal. The all-analog signal path and Nutube allow for genuine overdrive and distortion tones with the feel of a real tube amp, while internally boosted voltage gives greater headroom and dynamics. Plus, the OLED display shows an oscilloscope while the pedal is active or bypassed, allowing you to understand exactly how your signal is affected.

Three output modes allow you to use this as a standard pedal, a line-level preamp, and a direct amp-sim using the built-in analog cabinet simulator. Use STANDARD mode with your normal guitar rig to totally transform your amp, or use PREAMP or CAB-SIM mode while recording directly into your audio interface. In each mode, the all-analog design and active EQ allow you to perfectly dial in the sound you need in any situation.





FEATURES


Three output modes for use as a pedal or preamp

Selectable analog cabinet simulator
OLED display with oscilloscope
Active EQ to shape your signal



SPECIFICATIONS
INPUTS/OUTPUTS

INPUT jack, OUTPUT jack, DC9V jack, LINK jack

CONTROLS

GAIN knob, VOLUME knob, TREBLE knob, MIDDLE knob, BASS knob, BRIGHT switch, MODE switch

POWER SUPPLY*

1 x 9V alkaline battery or 9V center negative AC adaptor
*The use of an AC adaptor is recommended as the unit’s power consumption is relatively high. Should you prefer to use batteries, please use the alkaline type.

CURRENT CONSUMPTION

95 mA

BATTERY LIFE

Approx. 2 hours (When using the alkaline battery. This figure will vary depending on the actual conditions of use.)

DIMENSIONS (W X D X H)

72 mm x 120 mm x 55 mm/2.83″ x 4.72″ x 2.17″ (Including the switch and foot rubber)

WEIGHT

350 g/12.35 oz. (Excluding the battery)

INCLUDED ITEM

1 x 9V battery for checking operation

ACCESSORIES (SOLD SEPARATELY)

AC adaptor
