Behringer Eurocom CL208T 8 100V Ultra Compact 2-Way Loudspeaker, 200W RMS Power, Single,

Behringer CL208T Specs





Frequency Range
49 Hz to 20 kHz (-10 dB)


Frequency Response
55 Hz to 15 kHz (±3 dB)


Dispersion
NominalHorn Waveguide: 90 x 70º (H x V), rotatable


Directivity
Factor (Q): 7.5Index (DI): 8.8 dB


Sensitivity
1 W at 3.2' (1 m) Passive: 91 dB (half space)


Crossover
Modes: Passive


Crossover Frequency
2.5 kHz


Power Handling
200 W r.m.s (long term, IEC passive)


Nominal Impedance
4 Ω


Low Frequency Driver
2 x 8" (203.2 mm) at 150 W low-frequency cone transducers and a waveguide-mounted high-frequency dome driver


High Frequency Driver
1.35" (34.29 mm) at 30 W


SPL
Maximum Continuous: 114 dB SPL (passive)Maximum Peak: 120 dB SPL (passive)


Overload Protection
Full range power limiting to protect drivers and crossovers


Transformer
At 100 V: 50, 100, & 200 W


Enclosure
Trapezoidal 15° side angle, laminated birch plywood


Grille
Steel


Rigging Points
14 x M6 threaded points4 x M6 threaded inserts for OmniMount 30 series


Termination
5-position terminal strip connection


Dimensions (H x W x D)
28.4 x 10.2 x 11.9" (721.3 x 259.0 x 302.2 mm)


Weight
35.9 lb (16.2 kg)
