Darkglass Infinity 500 Combo 210

Input Jack
Use this jack to connect your instrument via a standard ¼” mono cable.

Headphone Output
Connect your Headphones and enjoy an IR emulating your cabinet sound.

Preset
Pressing the preset button changes through presets 1 to 5 and a bypass signal. Long press to store the current preset.

Input
Controls the amount of analog input gain. Press to activate/deactivate the effects loop for the preset.

Compression
Controls the amount of dynamic compression. The make up gain is adjusted automatically. Press to select between compressor OFF/Pre/Post drive position.

Drive
Controls the amount of gain of the selected drive mode. Press to select between: OFF/Leo Bass/Vintage Microtubes/Microtubes B3K/Alpha·Omega. Long press to access the Noise Gate threshold control.

Tone
Controls the Drivel tone/ Octaver filter. Press to select which control is active.

Level
Controls the Drive level/ Tweeter level. Press to select which control is active.

Blend
Controls the Drive blend/ Octaver blend. Press to select which control is active.
Preset Vol
Controls the preset volume. Press to toggle between the 7 IR slots/IR bypass for Post DI & Headphone OUT.

Graphic EQ section
Preset-specific Darkglass EQ. ± 12 dB @ Low Shelf/250 Hz/500 Hz/1.5 kHz/3 kHz/High Shelf.

Master
Controls the overall volume of the speaker and headphone outputs. Press for Mute + Tuner. Long press for Bluetooth pairing. (Audio+Suite).
