Behringer UB-Xa 16-voice Bi-timbral Polyphonic Analog Synthesizer

Polyphonic Analogue Synthesiser

• Reproduction of the classic OB-Xa including the original factory programmes
• 16-Voice multi-timbral
• 61 Semi-weighted velocity-sensitive keys with poly aftertouch
• Split and Layer function
• 8 Vintage modes
• Dual VCF
• 2 VCOs per voice and oscillator sync mode
• Both VCOs generate sawtooth, triangle or square waveforms with variable pulse width
• 2 Dedicated LFOs with 7 waveforms to modulate pulse width, oscillator pitch and filter cutoff frequency
• 2 ADSR generators per voice to control VCF and VCA
• Selectable analogue 12/24 dB low-pass filter with 2 slopes per voice and adjustable resonance
• Flexible 8-channel modulation matrix
• Dual-layer arpeggiator and sequencer with real-time sequence transposition
• 512 User programs can be stored with "Compare and Match" function for quick comparison of all analogue control elements with stored program values
• MPE
• LC display
• 26 Rotary controls for direct real-time access to all important parameters
• Foot pedal inputs for vibrato and filter: 2x 6.3 mm jacks
• Footswitch inputs for sustain, programme advance and hold: 3x 6.3 mm jacks
• Line outputs (L, R, mono): 3x 6.3 mm jacks
• Stereo headphone output: 6.3 mm jack
• MIDI In/Out/Thru
• USB
• Dimensions: 1045 x 109 x 350 mm
• Weight: 11.7 kg
