Euphonix Artist Control

Take Command of Your DAW with This Compact Controller! The Avid Artist Control v2 control surface combines the functionality of motorized faders, programmable knobs and buttons, and an incredible customizable touchscreen interface for maximum control over your DAW. Designed as a compact "nerve center" for your studio, the Artist Control v2 fits between your keyboard and computer monitor. Its high-resolution touchscreen lets you easily access and set up functions, while four touch-sensitive motorized faders, 12 Smart Keys, and eight programmable rotary encoders make the Artist Control v2 a powerful, flexible DAW controller!

The Avid Artist Control v2's high-resolution 800 x 480-pixel touchscreen interface displays all of your project's top-level information, including track names/numbers, metering (from mono to 5.1 surround data), fader/pan values, automation mode, etc. It also lets you quickly access all plug-in and EQ parameters, effortlessly setup macro commands for any function (or sequence of functions), and much more.

What's more, you can use the Artist Control v2's Smart Keys to trigger everything from simple keystroke commands to complex custom macros displayed on the touchscreen interface above - use the up/down arrows to scroll through an unlimited number of commands. Touch-sensitive rotary encoders offer direct control over everything from panning and gain to editing your most powerful plug-ins and EQ. These knobs can also be pressed to select/deselect and navigate through parameters. High-quality ALPS 100mm long-throw faders offer accurate and smooth mixing; touching a fader will automatically select the corresponding track.

Take advantage of the included Studio Monitor Express software. It provides professional monitoring (from stereo up to 5.1 surround) as well as complete talkback controls via any CoreAudio-compliant interface. Application Change and Workstation Change functions let you easily cycle through applications and switch between multiple workstations.

The Artist Control v2's ergonomic layout puts transport controls and a data-entry wheel at your fingertips, as well as keys to quickly select what parameter the wheel will modify (zoom horizontally/vertically, jog/shuttle, trimming clip head and tail, setting clip gain, crossfading, and more).

Avid Artist Control v2 Control Surface with Programmable Touchscreen Features at a Glance:

Customizable touchscreen interface (800 x 480 pixels)

v2 is more rugged than the original version

8 touch-sensitive rotary encoders

4 touch-sensitive motorized faders

12 assignable soft keys

Transport controls and jog/shuttle/zoom wheel

Studio Monitor Express software

High-speed EuCon Ethernet protocol

Mac OS X and Windows 7 compatible



The Avid Artist Control v2 puts you in command of your DAW!





Specification
Detail


Intended Use
Audio Mixer


Number of Faders
4


Fader Throw
100mm


Fader Type
Touch Sensitive, Motorized


Number of Knobs
9


Knob Type
Touch Sensitive rotary encoders


Number of Performance Pads
No performance pads


Performance Pad Types
No performance pads


Number of Soft Keys
35 dedicated soft keys, 12 assignable soft keys


Other Controls
Touchscreen


Transport Controls
Yes


Audio Inputs
No audio inputs


Audio Outputs
No audio outputs


Computer Connectivity
Ethernet


Control I/O
No control I/O


Height
1.2"


Depth
9.5"


Width
20"


Weight
5.5 lbs.


Manufacturer Part Number


9900-65171-00
