Metric Halo ULN-2 2d2J - FireWire Digital Audio Interface (2 Jensen Input Transformers) email print

The ULN-2 2d from Metric Halo is a portable, high quality FireWire based, multi-format audio converter and interface. Housed in a single space rack-mount chassis, the unit provides 12 inputs and 14 outputs of simultaneous I/O, while having the ability to be powered entirely from the FireWire bus of a laptop computer, or from an appropriate DC power source.


The ULN-2 2d is equipped with 2 balanced analog inputs on Neutrik combo connectors, 2 channels of digital I/O (AES/EBU and S/PDIF) and 8 channels of ADAT lightpipe I/O. Two balanced analog outputs and 2 balanced monitor outputs are available for connecting directly to power amps or self powered monitors. Wordclock I/O and dual FireWire connectors, along with 24-bit, 96kHz converters on all channels, make the ULN-2 2d a perfect tool for digital recording.


The unit is the perfect tool for capturing audio wherever inspiration hits, in the studio or on the road. Well suited to any recording situation, the microphone preamps provide exceptional detail and an ultra-fast slew rate. Fully balanced analog inserts allow outboard analog dynamics processing to be introduced between the preamps and the A/D converters.


On-board DSP powers the v.5 MIO Console that can function as a mixer, router and control application. The software can be used to route any input to any output, providing powerful and flexible mixing possibilities. A "Record Panel" allows for straight forward recording of incoming audio without the need for additional DAW software. This is particularly useful in situations where immediate editing is not required, but stable, fool-proof recording is.


Unit is equipped with Jensen input transformers on both analog input channels.

Hardware

Fully portable FireWire audio interface and format converter

Bus powered or use with external adapter that provides sufficient power for other peripherals 12 simultaneous input channels and 14 simultaneous output channels, all with full 24-bit/96kHz resolution 1

Please Note:

Totals include using 2-channels analog, 2 channels AES or S/PDIF, and 8-channels ADAT I/O

close

2 independent channels of high gain (up to +72dB), low-noise microphone-preamplification with switchable +48V phantom power Selectable stereo AES/EBU or S/PDIF digital inputs and outputs Up to 8-channels of ADAT Lightpipe input and output Wordclock I/O on BNC connectors Sample rate conversion (SRC) on AES or S/PDIF digital I/O Headphone amplifier with front panel volume knob Balanced stereo master control room monitor output with front panel volume control 10 front-panel preset system/routing memories for stand-alone operation 4-pin XLR power port for compatibility with most location battery systems Front panel metering for analog inputs and outputs OS X drivers with multi-interface support
MIO Software Consolev.5 Configurable mixer for near-zero latency mixing and routing Completely customizable mixing engine can be created from scratch or with any of the templates included - with the v.5 Mixer, the ULN-2 can be a mastering console in the morning, a tracking console in the afternoon, and a live sound mixer/recorder in the evening Record Panel provides no-frills, but very stable recoding feature for all inputs A single input can be multi-ed and given various levels of DSP processing and then recorded as separate tracks An arbitrary number of busses can be created (limited only by the capabilities of the hardware), each of which can be used as a master bus (routed to an output) or an auxiliary bus (routed to other busses), with bus able to be dynamically adjustable from mono to 7.1 surround Integrated surround monitor controller/switcher "Character" slot available on all channels provides analog modeling of various circuit types, including tube based electronics, etc. Full console metering of every channel and mix bus Total recall of every console parameter







Converters
24-bit


Sample Rates
44.1, 48, 88.2 and 96kHz


Analog Input
2 x Neutrik Combo (both inputs fitted with Jensen transformers)
2 x 1/4" TRS phone FX Return


Analog Output
4 x 1/4" TRS phone
2 x 1/4" TRS phone FX Send


Digital Input
1 x XLR AES/EBU
1 x RCA coaxial S/PDIF
1 x TOSlink ADAT lightpipe


Digital Output
1 x XLR AES/EBU
1 x RCA coaxial S/PDIF
1 x TOSlink ADAT lightpipe


MIDI In/Out
No


Sync In/Out
2 x BNC Wordclock I/O


Headphone Output
1 x 1/4" TRS phone


THD + N
0.0005% @ 1kHz (+9dBu in @ 6dB gain)


Dynamic Range
A/D: 110dB
D/A: 120dB


Frequency Response
8Hz to 50kHz, +/-1.0dB


Power Requirements
FireWire bus
1 x 4-pin XLR 9 to 30V DC (pin-4 hot) 15W
1 x 2.1 coaxial 9 to 30V DC, center post positive (+)


System Requirements
PowerPC or Intel Mac
OS X 10.3.9 or better
512MB RAM
Monitor with 1024 x 768 resolution or better
ASIO 2 compatible host (Cubase, Nuendo, Logic Audio, Digital Performer, Deck or Peak)
Application that supports ASIO direct monitoring for direct monitoring-based fold-back and overdubbing


Dimensions (WxDxH)
13.5 x 8.25 x 1.73" (343 x 210 x 44mm)


Weight
4 lbs (1.8 kg)


Specialties
Sample rate conversion (SRC) on digital I/O
