Earthworks PM40T PianoMic - Touring Piano Condenser Microphone System

The Earthworks PM40T Touring PianoMic System takes the PM40
PianoMic system and makes it an easily installed mobile microphone
system, ideal for touring. The PM40T uses an unconventional approach to
capturing piano with superior results while keeping the microphones
hidden from view. Two high-quality, random-incidence omnidirectional
microphones are mounted onto a telescoping bar for close-miking within
the piano itself.


The microphone capsules may be mounted to either
face, or point away from the dampers. The capsules themselves feature
flex-arm goosenecks that enable further microphone adjustments to be
made in order to achieve desired audio results. The PianoMic connects to
the 5-pin input of the PMVM1 electronics-box, which in turn features
3-pin XLR outputs for connecting to a stereo preamplifier, two mixer
channel inputs, etc.


While many experienced engineers may find the
close-miking technique unconventional, special technology ensures
optimum results and placement inside the piano means less leakage from
nearby instruments, speaker cabinets and other noise sources.


Internally Mounted Microphones
The PM40T PianoMic system mounts within the piano bed itself for maximum results and minimal visibility.

Random Incidence Omnidirectional Microphones
Superior quality, random-incidence omnidirectional capsule
compensate for transients and other issues involved with close-miking
pianos. The result is low-noise and an excellent quality suitable for
crucial recording and professional sound reinforcement applications.

Flexible Adjustments
The telescoping bar adjusts to fit any size piano and the
capsules are set onto flex-arm gooseneck for perfect microphone
placement.

Electronic Output Stage Box
A separate output stage box features a 5-pin XLR input and two
3-pin XLR outputs. A leather case with a strap allows the box to be
mounted onto a piano leg.












Transducer


Condenser



Polar Pattern


Omnidirectional



Frequency Response


9Hz to 40kHz



Dynamic Range (Typical)


72dB



Signal-to-Noise Ratio


22dBA SPL Equivalent (A Weighted)

24.5dB SPL Equivalent (Unweighted)



Maximum Input Sound Level


148dB



Power Requirements


48V Phantom 10mA



Output Impedance


600 ohms



Output Connectors


3-pin XLR x2



Pad


No



Low Frequency Roll-Off


No



Dimensions


Fully Extended: 64" (162.56cm)

Fully Collapsed: 46" (116.84cm)
Rod Length Separated: 23" (58.4cm) fully collapsed

Flex-Arm Length: 4.75" (12.06cm)



Weight


Mic Assembly: 0.75lb (350g)

Electronics Box: 1.5 lb (700g)







*Estimate Shipping between 5 - 12 weeks, or please call (083) 497-2227 for a faster air freight service with special price rate.
