Warm Audio EQP-WA Tube EQ

Warm Audio EQP-WA Tube EQ


OVERVIEW


Faithful recreation of the classic Pultec EQ units.





Warm Audio has carefully re-created the most renown tube Equalizer in studio history at an unheard of price. Not only does the look and feel of the EQP-WA match the classic Pultec units, but the sonic quality has been carefully considered by using top-end components such as CineMag transformers and premium tubes. This fully discrete Tube EQ can pull euphoric sonics from any track and bring a brilliance and luster to your final mixes that's nearly impossible to achieve inside-the-box. Warm Audio has once again redefined the industry standard and brought a fully professional-grade piece of outboard gear to the market at a price that's making history.




FEATURES

Tube Equalizer based on the classic "Pultec" EQP-1A
CineMag input and output transformers - Made in U.S.A.
Premium high voltage 12AX7 and 12AU7 tubes
CineMag inductor EQ section
EQ bypassable - signal still passes through tubes and transformers for warming effect
No insertion loss - loss restored by tube amplifier
XLR and TRS transformer balanced inputs
XLR and TRS transformer balanced outputs
Flat frequency response from 20 Hz - 50 kHz
Boost and Cut controls can be used simultaneously for phase effect




Get the warmth of the past in a current EQ design.






SPECIFICATIONS


EQP-WA Tube EQ



Low frequency boost - 20, 30, 60, 100, 200, 400, 800 Hz - 12 db
Low frequency cut - 20, 30, 60, 100, 200, 400, 800 Hz - 18 db
High frequency boost - 3, 4, 5, 8, 10, 12, 16 kHz - 18 db
High frequency cut - 3, 4, 5, 10, 20 kHz - 14 db
5 added frequency points for greater flexibility
Switchable 115/230 volt IEC power inlet
Dimensions: 19 x 3.5 x 6 inches - 2RU rack mountable
