Avid Eleven Rack Special Edition - Includes Pro Tools First

The Ultimate Guitar Interface!
Avid's Pro Tools | Eleven Rack is the ultimate recording interface and multi-effects box for guitarists. Recording, re-amping, and amazing live effects — Eleven Rack does it all! Powerful onboard DSP gives you the amazing sound of Avid's Eleven plug-in, without taxing your CPU or adding the least bit of latency. Experience lifelike tube amp response, thanks to Eleven Rack's True-Z impedance-matching technology. Take your signature studio tones to the stage. And by virtue of Eleven Rack's easy-to-use front panel and computer-based editing tools, customizing your sounds is a breeze. If you play guitar or bass, then you need Eleven Rack!




Amazing DSP-powered Pro Tools interface
Recording guitar can be tricky, but Avid's Eleven Rack makes it easy! Although it integrates into your Pro Tools rig like a plug-in, thanks to the Eleven Rack's onboard digital signal processing, you never have to worry about audible delay ruining your timing. That's because all the effects processing is happening right inside the Eleven Rack hardware. What's more, this means your guitar effects won't drain your computer's resources.






True-Z impedance-matching technology gives you lifelike tube amp response
Avid's True-Z impedance-matching circuitry makes the Eleven Rack a unique effects box and audio interface for guitar. This amazing circuit responds naturally to the dynamics of your guitar, just like a real amplifier. So the Eleven Rack doesn't just sound like a real guitar amplifier; it feels and responds like one too. This amazing technology has played a huge part in making the Eleven Rack one of the most popular guitar tools ever produced. Plug into an Eleven Rack, and discover it for yourself!




Take your favorite studio tones live onstage
Not only does the DSP in the Eleven Rack make it an exceptional recording tool, but it also features a hi-Z output, so you can hook it up directly to the input of your favorite amplifier. Set up your favorite effects conveniently in your studio, and then take them with you onstage. Need to change effects or tweak settings live? No problem! You can assign important settings to the Eleven Rack's front panel controls, access settings from the hardware, or hook up a MIDI footpedal to control effects as you play.


Surf-rock virtuoso Gary Hoey uses the Eleven Rack onstage




All-in-one re-amping rig lets you get creative with your tone
Have you ever recorded a guitar part, and then later wanted to go back and tweak the tone? The Eleven Rack makes this easy. As you record with Avid's Pro Tools, you can lay down both a mono dry signal and a stereo effects track. Even cooler, you can embed your effects settings right into the audio track, allowing you to recall and change settings at any time. And if you want to run your dry signal through your favorite amplifier, the guitarists here at Sweetwater have found that the Eleven Rack's instrument-level output acts as a traditional re-amping box too.




Easy-to-use front panel and computer-based editing tools
Tweaking modeling amps has seemed like a chore in the past, but Avid's Eleven Rack lets you quickly and easily customize your sound from the intuitive front panel controls or via standalone editing software. These robust interfaces make swapping out amps, changing cabs, and positioning mics a simple task. Creating a custom pedalboard is super fast and easy too. Add the pedal, tweak the sound, drag it to your desired point in the signal chain, and you're ready to go. Click here to download the standalone Eleven Rack Editor.





Avid Pro Tools | Eleven Rack Features:

DSP-driven USB 2.0 guitar recording interface and effects-processing system with direct integration into Pro Tools software (sold separately)
Onboard DSP frees up computer resources and provides latency effects for recording
Unique True-Z auto impedance-matching guitar input responds dynamically to your guitar or bass, just like a real amplifier
Powerful Eleven Rack control window for creating/editing Eleven Rack rig settings right from Pro Tools software
Records both dry and processed signals simultaneously, with recallable rig settings embedded into audio files
Includes over 70 professional effects, including reverb, delay, chorus, distortion, flanger, phaser, reverse, EQ, and compression
Incredible emulations of classic guitar amp tones inspired by Fender, Vox, Marshall, Soldano, and Mesa/Boogie amps
Refined collection of sought-after classic stompbox tones inspired by effects from Fender, Electro-Harmonix, Ibanez, Pro Co, Univox, and more
Powerful collection of studio-quality rackmount effects processors
Convolution-based cabinet emulations deliver unprecedented realism in cabinet tones
Convolution-based microphone emulations inspired by classic dynamic, condenser, and ribbon mic designs
Supports up to 8 simultaneous channels of high-resolution recording up to 24-bit/96kHz
1/4" hi-Z output for re-amping, which you can also use to plug the Eleven Rack straight into your amplifier live
Integrated FX loop switchable to incorporate existing mono or stereo rack and stompbox effects
Powerful foot control options using affordable MIDI controllers and expression pedals
Flexible I/O routing and functionality enables unit to be used in conjunction with nearly any existing rig setup
Built-in tuner and tap tempo control of time-based effects






Tech Specs

Computer Connectivity: USB
Form Factor: Rackmount
Simultaneous I/O: Up to 8 channels
Number of Preamps: 1 x guitar, 1 x mic
Phantom Power: Yes
A/D Resolution: 24-bit/96kHz
Built In DSP/FX: Amp modeling, Effects, Speaker Cabinet modeling, Mic modeling
Analog Inputs: 1 x 1/4" (Hi-Z), 1 x XLR (mic), 2 x 1/4" (line)
Analog Outputs: 2 x XLR (main), 2 x 1/4" (out to amp)
Digital Inputs: 1 x XLR (AES/EBU), 1 x Coax (S/PDIF)
Digital Outputs: 1 x XLR (AES/EBU), 1 x Coax (S/PDIF)
Inserts: 1 x Stereo Effects Loop
Headphones: 1 x 1/4"
Data I/O: 1 x 1/4" (expression/footswitch)
MIDI I/O: In, Out/Thru
USB: 1 x Type B
Software: Eleven Rack Editor, Pro Tools First License (download with free Avid account, iLok included)
OS Requirements - Mac: OS X 10.6.8 or later
OS Requirements - PC: Windows 7 SP1 or later
Rack Spaces: 2U
Power Supply: Standard IEC AC cable
Depth: 13.5"
Width: 19"
Height: 3.5"
Manufacturer Part Number: Elevenrack NO Software


approx. shipping weight = 21 lbs.
