Millennia STT-1 Origin Single Channel Channel Strip

Welcome to a Whole New Universe of Clean Audio!
The STT-1 Origin is a perfect go-to channel strip when you need a massive selection of tones without compromising audio quality. Not only is the complete signal path of the STT-1 Origin totally discrete, but it features Millennia's exclusive Twin Topology design that combines two completely separate and discrete amplifiers (one solid state, the other tube) into the same chassis. The STT-1 Origin's signal processing section also offers completely independent tube and solid state paths, and the input transformer is bypassable — giving you control-freak dominion over your sound. Capturing the vitality of musical performances with STT-1 Origin is almost effortless.
Millennia STT-1 Origin Complete Multi-Path Channel Strip at a Glance:

Twin Topology gives you two takes on clean audio
An incredible selection of signal processing for total sonic control

Twin Topology gives you two takes on clean audioThe core concept behind Twin Topology is that by completely separating the tube preamplifier path from the solid state preamplifier path, their different ways of handling voltage will not add coloration to one another. Both of these paths are ultra-clean, which calls into question some of the common misconceptions many people hold about tube technology. Rather than the kind of tubes featured in other high-end audio equipment, the M-2B vacuum tubes in the STT-1 Origin are balanced in such a way as to introduce very little coloration to the signal.
An incredible selection of signal processing for total sonic controlThe M-2B tube preamplifier is transparent, just like the solid state preamplifier, so why include both? The thing is that one kind of circuitry may be clean for one sound source, but not another. For example, on bass, the tube preamplifier can bring out some of the instrument's depth and maintain a great deal of headroom as it keeps the signal clear, while the solid state preamp may be better suited for recording an amplified guitar. And Twin Topology is only the beginning of the vast sonic possibilities that the STT-1 Origin offers. When you consider the twin optical de-esser paths, the twin NSEQ-2 mastering-grade parametric equalizer paths and the trio of optical compressor/limiter paths along with the multiple inputs of the Twin Topology preamplifiers and bypassable input transformer, you get over 130 premium audio topologies. That's a ton of sonic possibilities from a single signal path — and they all sound amazing!
Millennia STT-1 Origin Complete Multi-Path Channel Strip Features:

Over 130 optimized signal topologies
Twin microphone preamps — M-2B vacuum tube or HV-3 discrete solid state
Twin NSEQ-2 mastering-grade parametric equalizers — vacuum tube or discrete solid state
Three optical compressor/limiter paths — TCL vacuum tube, discrete solid state, passive
Twin optical De-Esser paths — vacuum tube or discrete solid state
Vacuum tube or discrete solid state line level paths
Input coupling with or without MIT-01 audio transformer
1/4" vacuum tube DI input — route via tube or solid state gain path
Effortless, lifelike musical performance at all levels
Musically rich vacuum tubes available
Gold audio connectors, tube sockets, relays and switches
3/8" thick radius extruded aluminum face plate
Durable black mirror-gloss anodized finish
Military spec 16 gauge cold-rolled steel chassis
Ultra-clean toroid power supply: internal sub-chassis
Hand machined aluminum knobs, illuminated IT&T pushbuttons
Mogami Neglex OFC audio wiring
Silver teflon power wiring
True audio VU meter for output level or dynamics gain reduction

Explore the uncharted possibilities of pristine audio with the Millennia STT-1 Origin channel strip!


Tech Specs



Preamp Type
Twin Topology: Tube and Solid State


Number of Channels
1


Frequency Response
5Hz-300kHz


Phantom Power
+48v


EQ
Yes


Compressor
Yes


Analog Inputs
2 x XLR


Analog Outputs
3 x XLR


Rack Spaces
2U


Height
3.5"


Depth
15.5"


Width
19"


Weight
25 lbs.


Manufacturer Part Number
STT-1
