RJM Mastermind PBC/6X

The Mastermind PBC/6X is RJM's response to all of customers who said “I like the PBC/10, but I want it smaller, less expensive, and I want to be able to change loop order on the fly!”The PBC/6X allows you to connect 6 pedals and have complete flexibility in choosing which pedals are on at any time, as well as the order of those pedals in your signal chain. You can also control any MIDI compatible devices and switch channels on most amps that use 1/4-inch switching jacks.Features:

6 audio loops
The last three loops are stereo capable using TRS jacks
Matrix switching for maximum routing flexibility
Flexible output that can be mono, stereo, or used as an A/B/Y switch
Mono mixdown feature allows you to mix down your stereo output to mono when using with a single amp
Two inputs, one with a switchable buffer
7 buttons, each with a multi-color LED indicator
Buttons are user configurable – any button can be set to any function and LED color
Easy to read backlit LCD display that can display preset and song names, plus other status
Built in tuner
MIDI connection, powered by the MIDI “brain” of our Mastermind GT controller. This MIDI port can be split into a MIDI input and output using a special Y cable
USB device port for connection to a PC or Mac. This allows the Mastermind PBC to send MIDI commands to a computer, or to communicate with the Mastermind Editor software
A 1/4-inch TRS jack that provides two function switches. These can be used to control the channel switching and other features on an amplifier, or for externally switchable features on certain pedals
Expression pedal input that can be programmed to generate MIDI messages based on the position of the pedal
External switch input allows two more switches to be added. These switches can be programmed to perform any function the internal buttons can
Mac and PC editor software allows for faster and more comprehensive editing, including deep MIDI editing and changing button layouts

Specs:

768 presets
1000 songs, 64 setlists
Can control up to 16 MIDI devices
20 MIDI messages can be assigned per button (PC, CC, Note, Sysex)
Dimensions: 10.1 (w) x 4.4 (d) x 2.4 (h) inches (25.7 (w) x 11.1 (d) x 6.1 (h) cm)
Weight: 2 lbs / 0.9 kg
Power Requirements: 9VDC or 12VDC 220mA, Boss-type connector (center negative 5.5/2.1mm barrel connector).



www.music-blvd.com $765.74
